ATH RG®10-6 WB

6-column set with master control – expandable up to 16 columns

Availability: In stock

SKU

710072

Share on

Electro-hydraulic wheel gripper system with battery operation and wireless control
Control unit including unit cover on each column for flexible use
Master unit controls all operating information on each column and an extension up to 16 columns
Integrated quick charger per column, enables charging during use.
Mobile kit and forklift attachment on the columns enable a faster change of position
Safety Control: hydraulic shut-off valve, electronic synchronization monitoring and electromagnetic safety locks
Safety Lock: ability to lock the load on to the safety mechanism
Multifunctional mounting via variable wheel fork with individual setting options

More Information
Capacite de levage	10.000 kg
Hauteur de levee maxi	1.850 mm
Hauteur totale	2.650 mm
Largeur de la colonne	1.145 mm
Puissance d’entraînement	2,2 kW
Temps monte / descente	65s / 55s
Tension	DC 24V
Communication avec la colonne	wireless
Dalle beton	min. C20/25 Dicke: 200 mm
